KEMET®
CERAMIC CONFORMALLY COATED/RADIAL
“GOLDEN MAX”
STANDARD LEAD CONFIGURATION — OUTLINE DRAWINGS
*.276 (7.00) MIN.
L
T
C315
C320
C330
C340
C350
C317
C322
.060
(1.52)
MAX.
C323
C333
H
H
H
H
*
*
D
*
*
S
S
S
S
Drawings are not to scale. See table below for dimensions.
See page 9 for optional lead configurations.
DIMENSIONS — INCHES & MILLIMETERS
CASE
SIZE
L
H
MAX.
T
S(1)
.030
D
MAX.
MAX.
+.004 - .001
C315
C317
C320
C322
C323
C330
C333
C340
.150 (3.81)
.150 (3.81)
.200 (5.08)
.200 (5.08)
.200 (5.08)
.300 (7.62)
.300 (7.62)
.400 (10.16)
.500 (12.70)
.210 (5.33)
.230 (5.84)
.260 (6.60)
.260 (6.60)
.320 (8.13)
.360 (9.14)
.390 (9.91)
.460 (11.68)
.560 (14.22)
.100 (2.54)
.100 (2.54)
.125 (3.18)
.125 (3.18)
.125 (3.18)
.150 (3.81)
.150 (3.81)
.150 (3.81)
.200 (5.08)
.100 (2.54)
.200 (5.08)
.100 (2.54)
.200 (5.08)
.200 (5.08)
.200 (5.08)
.200 (5.08)
.200 (5.08)
.400 (10.16)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
.025 (.64)
C350
NOTE: 1 inch = 25.4 mm.
NOTE: (1) Measured at seating plane.
ORDERING INFORMATION
102
C A
*
C 320 C
M
R 5
1
CERAMIC
FAILURE RATE
A — Not Applicable
CASE SIZE
(See Table Above)
LEAD MATERIAL
C — Standard
SPECIFICATION
INTERNAL
C — Standard
CONSTRUCTION
5 — Standard
CAPACITANCE, CODE
Expressed in Picofarads (pF)
First Two Digits — Significant Figures
Third Digit — Number of Zeros (Use 9 for 1.0
thru 9.9 pF. Example: 2.2pF — 229)
DIELECTRIC
EIA Designation
G — C0G (NP0) — Ultra-Stable
R — X7R — Stable
U — Z5U — General Purpose
CAPACITANCE TOLERANCE
D — ±0.5 pF
F — ±1%
G — ±2%
J — ±5%
K — ±10%
M — ±20%
Z — -20, +80%
RATED VOLTAGE
2 — 200
1 — 100
5 — 50
*Part Number Example: C320C102M1R5CA (14 digits – no spaces)
For packaging information, see pages 33 and 34.
8
KEMET Electronics Corporation, P.O. Box 5928, Greenville, S.C. 29606, (864) 963-6300
