KEMET®
CERAMIC CONFORMALLY COATED/AXIAL
“AXIMAX”
CAPACITANCE OUTLINE DRAWING
LL
L
D
LD
MAXIMUM DIMENSIONS—INCHES & (MILLIMETERS)
LD
STYLE
L
MAX
D
MAX
LL
MIN
+.001, -.003
(+.025, -.076)
C410
C412
C420
C430
C440
.170 (4.32)
.170 (4.32)
.260 (6.60)
.290 (7.37)
.400 (10.16)
.100 (2.54)
.120 (3.05)
.100 (2.54)
.150 (3.81)
.150 (3.81)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
.020 (.51)
1.0 (25.4)
1.0 (25.4)
1.0 (25.4)
1.0 (25.4)
1.0 (25.4)
ORDERING INFORMATION
104
C A
*
C 410 C
M
U 5
5
CERAMIC
FAILURE RATE
A — Not Applicable
CASE SIZE
(See Table of Dimensions above)
LEAD MATERIAL
C — Standard
SPECIFICATION
C — Standard
INTERNAL CONSTRUCTION
5 — Standard
CAPACITANCE
DIELECTRIC
Expressed in Picofarad Code (pF)
First Two Digits — Significant Figures
Third Digit — Number of Zeros
EIA Designation
G — C0G (NPO) — Ultra-Stable
R — X7R — Stable
U — Z5U — General Purpose
CAPACITANCE TOLERANCE
J — ±5%
K — ±10%
RATED VOLTAGE
1 — 100 Volts
5 — 50 Volts
M — ±20%
Z — –20 +80%
*Part Number Example: C410C104M5U5CA (14 digits – no spaces)
MARKING INFORMATION
Rated Voltage
Dielectric
5 - 50 volts
G – C0G/NP0
R – X7R
Manufacturer
(KEMET)
1 - 100 volts
U – Z5U
K5R
104K
AB
0037
Capacitance
Code
Capacitance
Tolerance
Lot
Date
Code
Code
6
