Micro Edgeboard - .050” Contact Spacing
Jackscrew/Jackpost Assembly (MEB 64 & 128 Sizes Only)
Jackpost Kit
MEB
RECEPTACLE
CONNECTOR
PLUG
CONNECTOR
RETAINING
PIN
RETAINING
PIN
MEB plug or receptacle-P/N 320-9514-001
Contains 2 bushings and 4 spirals pins
JACKPOST
Jackscrew
JACKPOST
MEB plug-P/N 320-9521-001
MEB receptacle-P/N 320-9521-000
Contains 2 jackscrew assemblies
.260
(6.60)
MAX.
#2-56
UNC-2A
THREAD
#2-56
UNC-2A
THREAD
.790 ± .010
20.07 ± 0.25)
WASHER
[.022 (0.56) thk]
WASHER
[.032 (0.81) THK]
RETAINING
PIN
JACKSCREW
ASSEMBLY
RETAINING
PIN
.045
(1.14)
REF.
.270 (6.86)
MAX.
JACKSCREW
ASSEMBLY
Plug
Receptacle
with Jackscrew
with Jackscrew
Special Variations
Alternative Receptacle Configuration
.200
(5.08)
MIN.
4-40 UNC-THD
THRU HOLE
.016
(0.41)
DIA.
.100
(2.54)
31 PLACES
.275
(6.99)
.580
(14.73)
.285
(7.24)
MAX.
.030
(0.76)
.110
(2.79)
2 PLACES
.060
.250
(6.35)
.125 +_ .010
(3.18 +_ 0.25)
2 PLACES
(1.52)
Dimensions shown in mm
Specifications and dimensions subject to change
