D Subminiature
Combo D
ɍ
ɍɍ
40 A High Power 90° — Standard Footprint .489 or .454 inch (Size DD)
Receptacle
Part Numbers with Metal Bracket and Rivnut # 4-40 UNC
Part Number
Without Screw Locks
Without Boardlocks
Part Number
Without Screw Locks
With Boardlocks
Part Number
With Screw Locks
Without Boardlocks
Part Number
With Screw Locks
With Boardlocks
Shell Size
DD
Layout
24W7
36W4
43W2
47W1
DDMP24H7SJA197
DDMP36H4SJA197
DDMP43H2SJA197
DDMP47H1SJA197
DDMC24H7SJA197
DDMC36H4SJA197
DDMC43H2SJA197
DDMC47H1SJA197
DDMD24H7SJA197
DDMD36H4SJA197
DDMD43H2SJA197
DDMD47H1SJA197
DDMG24H7SJA197
DDMG36H4SJA197
DDMG43H2SJA197
DDMG47H1SJA197
DD
DD
DD
Note: For contacts with 30 microinches gold substitute K126 for A197. Example: DDMP24H7SJK126
Reader’s Resource
ɀ For contact cavity arrangements,
see page 223.
ɀ For P.C. hole patterns, see page 249.
ɀ For panel cutouts, see page 221.
ɀ For alternate bracket configuration (when
connectors are supplied without boardlocks),
see page 226.
Engaging Face
A
B
3,89 (.153)
MIN
C
20,57 ± 0,38
(.810 ± .015)
E
D
L
2,92
(.115)
10°
Ø 3,18
(.125)
BOARDLOCK
Ø 0,76
(.030)
Screw lock, boardlock, and signal contacts
removed for clarity
2,84
(.112)
4,33 ± 0,38
(.170 ± .015)
5,68
(.224)
BRACKET,
METAL
RIVNUT
#4-40 UNC
13,74
(.541)
11,53 ± 0,25
(.454 ± .010)
10,06
(.396)
F
W
6,50 ± 0,25
(.256 ± .010)
SCREW LOCK
#4-40 UNC
Screw lock, boardlock, and high power contact
removed for clarity
Note: ɋ Dimension varies with alternate bracket configuration, see page 226.
Dimensions
A
B
C
D
E
F
W
L
Shell Size
0,38 (.015)
0,13 (.005)
0,13 (.005)
0,13 (.005)
0,38 (.015)
0,25 (.010)
0,38 (.015)
0,25 (.010)
DD
66,93 (2.635)
52,42 (2.064)
61,11 (2.406)
10,74 (.423)
15,37 (.605)
10,90 (.429)
6,94 (.273)
0,76 (.030)
ɍ Connector footprint measured from the front shell.
ɍɍ Connector footprint measured from the rear shell.
Dimensions are shown in mm (inch)
Dimensions subject to change
63
ITT [ ITT Cannon ]
