D Subminiature
Combo D
ɍ
ɍɍ
40 A High Power 90° — Standard Footprint .489 or .454 inch (Size DD)
Plug
Part Numbers with Metal Bracket and Rivnut # 4-40 UNC
Part Number
Without Screw Locks
Without Boardlocks
Part Number
Without Screw Locks
With Boardlocks
Part Number
With Screw Locks
Without Boardlocks
Part Number
With Screw Locks
With Boardlocks
Shell Size
DD
Layout
24W7
36W4
43W2
47W1
DDMP24H7PJK87
DDMP36H4PJK87
DDMP43H2PJK87
DDMP47H1PJK87
DDMC24H7PJK87
DDMC36H4PJK87
DDMC43H2PJK87
DDMC47H1PJK87
DDMD24H7PJK87
DDMD36H4PJK87
DDMD43H2PJK87
DDMD47H1PJK87
DDMG24H7PJK87
DDMG36H4PJK87
DDMG43H2PJK87
DDMG47H1PJK87
DD
DD
DD
Note: For contacts with 30 microinches gold substitute K127 for K87. Example: DDMP24H7PJK127
Reader’s Resource
ɀ For contact cavity arrangements,
see page 222.
ɀ For P.C. hole patterns, see page 246.
ɀ For panel cutouts, see page 221.
ɀ For alternate bracket configuration (when
connectors are supplied without boardlocks),
see page 226.
Engaging Face
A
3,89 (.153)
MIN
C
B
20,57 ± 0,38
(.810 ± .015)
D
E
L
2,92
(.115)
BOARDLOCK
10°
Screw lock, boardlock, and signal contacts
removed for clarity
3.18
(.125)
0,76
Ø
(.030)
Ø
2,84
(.112)
4,33 ± 0,38
(.170 ± .015)
5,68
(.224)
BRACKET,
METAL
13,74
(.541)
RIVNUT
#4-40 UNC
11,53 ± 0,25
(.454 ± .010)
10,06
(.396)
F
W
6,50 ± 0,25
(.256 ± .010)
SCREW LOCK
#4-40 UNC
Screw lock, boardlock, and high power contact
removed for clarity
Note: ɋ Dimension varies with alternate bracket configuration, see Reader’s Resource page 226.
Dimensions
A
B
C
D
E
F
W
L
Shell Size
0,38 (.015)
0,13 (.005)
0,13 (.005)
0,13 (.005)
0,38 (.015)
0,25 (.010)
0,41 (.016)
0,25 (.010)
DD
66,93 (2.635)
52,81 (2.079)
61,11 (2.406)
11,07 (.436)
15,37 (.605)
10,82 (.426)
6,84 (.269)
0,99 (.039)
ɍ Connector footprint measured from the front shell.
ɍɍ Connector footprint measured from the rear shell.
Dimensions are shown in mm (inch)
Dimensions subject to change
62
ITT [ ITT Cannon ]
