D Subminiature
D*
ɍ
ɍɍ
90° Solder Termination (Machined) with Metal Bracket — European Footprint 10,2 or 9,4 mm
Receptacle
Part Numbers
Bushing with
Through Hole
Captive Nut
# 4-40 UNC
Captive Nut
M3
Post
Shell Size
DE
Layout
# 4-40 UNC
9
15
25
37
50
DE9S-1AFN-A197
DA15S-1AFN-A197
DB25S-1AFN-A197
DC37S-1AFN-A197
DD50S-1AFN-A197
DE9S-1A7N-A197
DA15S-1A7N-A197
DB25S-1A7N-A197
DC37S-1A7N-A197
DD50S-1A7N-A197
DE9S-1A9N-A197
DA15S-1A9N-A197
DB25S-1A9N-A197
DC37S-1A9N-A197
DD50S-1A9N-A197
DE9S-1A8N-A197
DA15S-1A8N-A197
DB25S-1A8N-A197
DC37S-1A8N-A197
DD50S-1A8N-A197
DA
DB
DC
DD
Selection Guide
ɀ For Product Features, Specifications,
Materials and Finishes, see pages 14-15.
Notes: For pushfit/boardlock option add -146. Example: DE9S-1AFN-A197-146
For performance class 2 add -A191. Example: DE9S-1AFN-A191-A197
Reader’s Resource
ɀ For contact cavity arrangements,
see page 224.
ɀ For P.C. hole patterns, see page 273.
ɀ For panel cutouts, see page 221.
ɀ For hardware views (European),
see page 227.
Engaging Face
DD Configuration
2,54 (.100)
5,08 (.200)
3,70 (.146)
L
9,40 (.370)
3,70 (.146)
2,54 (.100)
F
W
9,40 (.370)
Dimensions
A
B
C
D
E
F
W
L
Shell Size
DE
0,38 (.015)
0,13 (.005)
16,33 (.643)
24,66 (.971)
38,38 (1.511)
54,84 (2.159)
52,42 (2.064)
0,13 (.005)
0,13 (.005)
0,38 (.015)
0,25 (.010)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
0,38 (.015)
0,25 (.010)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
7,90 (.311)
7,90 (.311)
7,90 (.311)
7,90 (.311)
10,74 (.423)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
DA
DB
DC
DD
ɍ Connector footprint measured from the front shell.
ɍɍ Connector footprint measured from the rear shell.
Dimensions are shown in mm (inch)
Dimensions subject to change
