ZIF Connectors
DLM
DLM Product Introduction
annon has expanded the DL-ZIF Series
offering with the addition of the DLM
(Metal Shell) versions. The DLM uses a
C
rugged nickel plated aluminum housing. The
Shield-Locking Mechanism feature (see
illustration below) ensures uniform mating
pressure around the perimeter of the mated
connector to create an EMI/RFI shield. Facilitates
compliance of equipment to CE EMC directives.
The DLM1/2/3 connectors are an extension of the The DLM Series are offered with the 3,18(.125)
DL line, similar to the current DLM5 and DLM6 long 0,64(.025) square post 50µ inch gold
products.The DLM series connectors are inter- contacts, as well as the 4,50(.177) long
mateable to the DL (Plastic) versions for X 0,50(.020) PC/RC round tail contacts.
backwards/forwards compatibility.
Materials and Finishes
DLM1/2/3/5/6 Housing Aluminum alloy, nickel plated
DLM1/2/3/5/6 Insulator Glass filled thermoplastic, UL 94V-0 rated, Color: Black
Crimp Contact* Copper alloy, 50µ inches gold over 50µ inches nickel in mating area, gold flash on balance
Copper alloy, 20µ inches gold over 50µ inches nickel in mating area, tin lead on balance
Square Post Contact Copper alloy, 50µ inches gold over 50µ inches nickel in mating area, gold flash on balance
Copper alloy, 20µ inches gold over 50µ inches nickel in mating area, gold flash on balance
PC/RC Contact Copper alloy, 20µ inches gold over nickel in mating area, tin lead on balance
Actuating Camshaft Stainless steel, Passivated
Insulator Retainer (Plug Only) Stainless steel, Passivated
*Order crimp contacts separately, see pages 52-53.
Dimensions are shown in mm (inch)
Dimensions subject to change
