Mobile Intel Pentium 4 Processor-M
Revision History
Date
Revision
Description
March 2002
April 2002
001
002
Initial release of the Datasheet
Updates include:
•
•
•
•
Added new processor speeds: 1.4 GHz, 1.5 GHz, & 1.8 GHz
Added PROCHOT# signal in Table 21
Updated signal description for PROCHOT# in Table 37 and Section 6.1.2
Updated the description of the Enhanced Intel Speedstep Technology in
sections 2.4.1 and 7.3
•
Updated PWRGOOD signal in Table 3, Section 2.7, Table 14, Table 21,
Table 28, Table 35, Figure 28, and FIgure 29
June 2002
003
004
Updates include:
•
•
Added specifications for new processor speeds: 1.90 GHz and 2 GHz
Added die length and die width for processors based on B0-step shrink
process in Table 33
September 2002
Updates include:
•
•
•
Added 2.2 GHz Mobile Intel Pentium 4 Processor-M specifications.
Current and power specifications updated in Table 7 & Table 38.
Corrected STPCLK#/SLP# timing relationship in Section 7.2.3 to match
parameter T75.
January 2003
005
Updates include:
•
•
•
•
Added 2.4 GHz Mobile Intel Pentium 4 Processor-M specifications.
Current and power specifications updated in Table 7 & Table 38.
Clarified DBI[3:0]# and THERMTRIP# descriptions in Table 37.
Clarified thermal solution requirements in Section 6.
April 2003
June 2003
006
007
Updates include:
•
•
Added 2.5 GHz Mobile Intel Pentium 4 Processor-M specifications.
Current and power specifications updated in Table 7 & Table 38.
Updates include:
•
•
•
Added 2.6 GHz Mobile Intel Pentium 4 Processor-M specifications.
Updated note 5 in Table 22.
Updated THERMTRIP# description in Table 37.
8
Mobile Intel Pentium 4 Processor-M Datasheet
