Electrical Specifications
2.
Electrical Specifications
2.1
System Bus and GTLREF
Most Mobile Intel Pentium 4 Processor-M system bus signals use Assisted Gunning Transceiver
Logic (AGTL+) signalling technology. As with the Intel P6 family of microprocessors, this
signalling technology provides improved noise margins and reduced ringing through low-voltage
swings and controlled edge rates. The termination voltage level for the Mobile Intel Pentium 4
Processor-M AGTL+ signals is V , which is the operating voltage of the processor core. Previous
CC
generations of Intel mobile processors utilize a fixed termination voltage known as V . The use
CCT
of a termination voltage that is determined by the processor core allows better voltage scaling on
the system bus for Mobile Intel Pentium 4 Processor-M. Because of the speed improvements to
data and address bus, signal integrity and platform design methods have become more critical than
with previous processor families. Design guidelines for the Mobile Intel Pentium 4 Processor-M
system bus will be detailed in the Mobile Intel Pentium 4 Processor-M and Intel 845MP/
845MZ Chipset Platform Design Guide.
The AGTL+ inputs require a reference voltage (GTLREF) which is used by the receivers to
determine if a signal is a logical 0 or a logical 1. GTLREF must be generated on the system board.
Termination resistors are provided on the processor silicon and are terminated to its core voltage
(V ). Intel’s 845MP/845MZ chipsets will also provide on-die termination, thus eliminating the
CC
need to terminate the bus on the system board for most AGTL+ signals. However, some AGTL+
signals do not include on-die termination and must be terminated on the system board. For more
information, refer to the Mobile Intel Pentium 4 Processor-M and Intel 845MP/845MZ
Chipset Platform Design Guide.
The AGTL+ bus depends on incident wave switching. Therefore, timing calculations for AGTL+
signals are based on flight time as opposed to capacitive deratings. Analog signal simulation of the
system bus, including trace lengths, is highly recommended when designing a system.
2.2
2.3
Power and Ground Pins
For clean on-chip power distribution, the Mobile Intel Pentium 4 Processor-M have 85 VCC
(power) and 181 VSS (ground) inputs. All power pins must be connected to VCC, while all VSS pins
must be connected to a system ground plane.The processor VCC pins must be supplied with the
voltage determined by the VID (Voltage ID) pins and the loadline specifications (see Figure 4 to
Figure 6).
Decoupling Guidelines
Due to its large number of transistors and high internal clock speeds, the processor is capable of
generating large average current swings between low and full power states. This may cause
voltages on power planes to sag below their minimum values if bulk decoupling is not adequate.
Care must be taken in the board design to ensure that the voltage provided to the processor remains
within the specifications listed in Table 7. Failure to do so can result in timing violations and/or
Mobile Intel Pentium 4 Processor-M Datasheet
13
