General Purpose Timer Units (GPT12)
15.2.1
Block Diagram GPT1
Block GPT1 contains three timers/counters: The core timer T3 and the two auxiliary timers T2 and T4. The
maximum resolution is fGPT/4. The auxiliary timers of GPT1 may optionally be configured as reload or capture
registers for the core timer.
T3CON.BPS1
2n : 1
Basic clock
fGPT
Interrupt Request
(T2IRQ)
Aux. Timer T2
Core Timer T3
Aux. Timer T4
U/D
T2IN
T2
Mode
Control
Capture
Reload
T2EUD
Toggle Latch
T3
Mode
Control
T3IN
T3OTL
T3OUT
U/D
T3EUD
Interrupt Request
(T3IRQ)
Capture
Reload
T4IN
T4
Mode
Control
T4EUD
Interrupt Request
(T4IRQ)
U/D
MC _GPT0101_bldiax1.vsd
Figure 19 GPT1 Block Diagram (n = 2 … 5)
