TLE9263QX
Voltage Regulator 2
7.3
Electrical Characteristics
Table 10
Electrical Characteristics
VS = 5.5 V to 28 V; Tj = -40 °C to +150 °C; all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Unit Note / Test Condition Number
Min. Typ. Max.
Output Voltage including line
and Load regulation
(SBC Normal Mode)
VCC2,out1
4.9
5.0
5.1
V
1)SBC Normal Mode;
10µA < IVCC2 < 100mA
6.5V < VS < 28V
P_7.3.1
Output Voltage including line
and Load regulation
(SBC Normal Mode)
VCC2,out2
4.9
5.0
5.1
V
1)SBC Normal Mode;
10µA < IVCC2 < 80mA
6V < VS < 28V
P_7.3.16
Output Voltage including line
and Load regulation
(SBC Normal Mode)
VCC2,out3
4.9
5.0
–
5.1
V
V
1)SBC Normal Mode;
10µA < IVCC2 < 40mA
P_7.3.2
Output Voltage including line
and Load regulation
(SBC Normal Mode)
VCC2,out4
4.97
5.07
2)SBC Normal Mode;
10µA < IVCC2 < 5mA
8V < VS < 18V
P_7.3.14
25°C < Tj < 125°C
Output Voltage including line
and Load regulation
(SBC Stop/Sleep Mode)
VCC2,out5
VCC2,out6
VCC2,d1
4.9
4.9
5.05 5.2
V
V
Stop, Sleep Mode;
1mA < IVCC2 < IVCC2,Ipeak
P_7.3.3
Output Voltage including line
and Load regulation
(SBC Stop/Sleep Mode)
5.05 5.25
Stop, Sleep Mode;
10µA < IVCC2 < 1mA
P_7.3.18
Output Drop
–
–
–
500
3.5
mV
mA
I
VCC2 = 30mA
P_7.3.4
VS = 5V
2)ICC2 rising;
VS = 13.5V
-40°C < Tj < 150°C
VCC2 Active Peak Threshold IVCC2,Ipeak,r
(Transition threshold between
low-power and high-power
mode regulator)
1.9
P_7.3.15
VCC2 Active Peak Threshold IVCC2,Ipeak,f 0.5
(Transition threshold between
high-power and low-power
1.3
–
–
mA
2)ICC2 falling;
VS = 13.5V
-40°C < Tj < 150°C
P_7.3.17
P_7.3.5
mode regulator)
Over Current limitation
IVCC2,lim
100
7502) mA
current flowing out of
pin, VCC2 = 0V
1) In SBC Stop Mode, the specified output voltage tolerance applies when IVCC2 has exceeded the selected active peak
threshold (IVCC2,Ipeak,r) but with increased current consumption.
2) Not subject to production test, specified by design.
