TLE 6250
Electrical Characteristics
Absolute Maximum Ratings
Parameter
Symbol Limit Values Unit
min. max.
Remarks
Voltages
Supply voltage
VCC
– 0.3 6.5
40
V
V
–
–
CAN input voltage
(CANH, CANL)
VCANH/L – 40
Logic voltages at
VI
– 0.3 VCC
V
0 V < VCC < 5.5 V
INH, RM, TxD, RxD
Electrostatic discharge
voltage at CANH,CANL
VESD
VESD
– 6
– 2
6
2
kV
kV
human body model
(100 pF via 1.5 kΩ)
Electrostatic discharge
voltage
human body model
(100 pF via 1.5 kΩ)
Temperatures
Junction temperature
Tj
– 40
160
°C
–
Note: Maximum ratings are absolute ratings; exceeding any one of these values may
cause irreversible damage to the integrated circuit.
