TLE 6250
Electrical Characteristics
4.5 V < VCC < 5.5 V; RL = 60 Ω; VINH < VINH,ON; – 40 °C < Tj < 150 °C; all voltages with
respect to ground; positive current flowing into pin; unless otherwise specified.
Parameter
Symbol
Limit Values
Unit Remarks
min. typ. max.
Current Consumption
Current consumption
ICC
–
–
–
–
6
10
70
10
10
mA recessive state;
V
TxD = VCC
mA dominant state;
TxD = 0 V
Current consumption
Current consumption
Current consumption
ICC
45
6
V
ICC
mA receive-only mode;
RM = low
ICC,stb
1
µA stand-by mode;
TxD = RM = high
Receiver Output R×D
HIGH level output
current
IRD,H
IRD,L
–
-4
4
-2
mA VRD = 0.8 × VCC,
Vdiff < 0.4 Vnote 1)
LOW level output
current
2
–
mA VRD = 0.2 × VCC,
Vdiff > 1 Vnote 1)
Transmission Input T×D
HIGH level input voltage VTD,H
threshold
–
0.5× 0.7×
V
recessive state;
dominant state
–
VCC
VCC
LOW level input voltage VTD,L
threshold
0.3× 0.4×
VCC
10
–
V
VCC
25
TxD pull up resistance
RTD
50
kΩ
note1) Vdiff = VCANH – VCANL
