TLE 6250 V33
Electrical Characteristics (cont’d)
4.5 V < VCC < 5.5 V; (3.0 V < V33V < 3.6 V for 3.3 V version); RL = 60 Ω; VINH < VINH,ON
;
– 40 °C < Tj < 150 °C; all voltages with respect to ground; positive current flowing into
pin; unless otherwise specified.
Parameter
Symbol
Limit Values
Unit Remarks
min. typ. max.
Bus Receiver
Differential receiver
threshold voltage,
recessive to dominant
edge
Vdiff,d
–
0.75 0.90
V
V
V
– 20 V < (VCANH
CANL) < 25 V
Vdiff = VCANH – VCANL
,
V
Differential receiver
threshold voltage
dominant to recessive
edge
Vdiff,r
0.50 0.60
–
– 20 V < (VCANH
CANL) < 25 V
Vdiff = VCANH – VCANL
,
V
Common Mode Range
CMR
-20
–
25
VCC = 5V
Differential receiver
hysteresis
Vdiff,hys
–
150
–
mV –
CANH, CANL input
resistance
Ri
10
20
20
40
30
60
kΩ recessive state
kΩ recessive state
Differential input
resistance
Rdiff
