    TLD7002-16ES 参数 Datasheet PDF下载

    TLD7002-16ES图片预览
    型号： TLD7002-16ES
    PDF下载： 下载PDF文件 查看货源
    内容描述： [The TLD7002-16ES is a 16 channel device with integrated and protected output stages. It is designed to control LEDs with a current up to 76.5 mA as linear current sink (LCS). The power stages can be configured in parallel for higher load currents. Each individual power output stage is configured to a 6-bit current set value stored in the OTP. 16 independent and individual PWM configurations can be set. A high-speed lighting interface is used for device OTP programming, configuration, control and]
    分类和应用：
    文件页数/大小： 82 页 / 3105 K
    品牌： INFINEON [ Infineon ]
     浏览型号TLD7002-16ES的Datasheet PDF文件第54页浏览型号TLD7002-16ES的Datasheet PDF文件第55页浏览型号TLD7002-16ES的Datasheet PDF文件第56页浏览型号TLD7002-16ES的Datasheet PDF文件第57页浏览型号TLD7002-16ES的Datasheet PDF文件第59页浏览型号TLD7002-16ES的Datasheet PDF文件第60页浏览型号TLD7002-16ES的Datasheet PDF文件第61页浏览型号TLD7002-16ES的Datasheet PDF文件第62页
    TLD7002-16ES
    Datasheet
    9 Communication interface
    9.1.11.5
    HWCR frame
    The purpose of the hardware control frame is to clear the diagnostic flags. The data transfer to the slave is organized
    in dedicated write frame, containing
    •
    •
    •
    •
    the sync byte, provided by the master
    the address byte, provided by the master
    the MRC_DLC_FUN byte, provided by the master
    the RESET diagnostic words (RESET_OVERLOAD, RESET_OPENLOAD, RESET_SLS, RESET_STATUS), provided by
    the master
    •
    •
    •
    the safety byte (CRC-8), provided by the master
    the output status byte, provided by the slave and the
    Acknowledge byte (ACK) provided by the slave.
    The HWCR frame requires following field configurations:
    •
    •
    DLC[5:3] = 0x3 for 4 words respectively 8 bytes for the reset diagnostic words
    FUN[2:0] = 0x3
    The slave response bytes "output status byte and acknowledge byte" are skipped in case the frame is sent to the
    broadcast address. Consequently there is no response from the slave to the master provided.
    The slave ignores and discards frames in case of an unexpected DLC or FUN data as described in Chapter 9.1.11.10.
    The HWCR frame requires following field configurations to retrieve diagnostics only:
    •
    •
    DLC[5:3] = 0x0 for output status bytes only
    FUN[2:0] = 0x3
    The HWCR frame is shown in Figure 25.
    Datasheet
    58
    Rev.1.00
    2022-05-03
