TDA5235
Revision Number:
Revision History:
010
2010-02-19
V1.0
Previous Version:
Page
TDA5235_V0.1
Subjects (major changes since last revision)
Update of Figure 9
Page 25
Page 27
Update of Figure 10
Page 29
AFC limitation added
Page 31
AGC setting proposal added
Page 32
New Section 2.4.6.5 ADC added
Additional information on RSSIPRX register inserted
Signal and Noise Detector Procedure adapted
x_CDRRI register recommendation changed
Data Slicer Modes adapted; limitation added
Update of Figure 41
Page 34
Page 39
Page 43
Page 47, 50, 54
Page 67
Page 68
Update of Figure 42
Page 76
Additional hint on clock and data recovery algorithm of the user
software inserted
Page 82
PLDLEN limitation added
Page 84
Limitation for ISx readout and Burst-read function added
Limitation for Burst-read function added
Description of “Parallel Wake-up Search” adapted
Additional hints added
Page 86
Page 105
Page 123
Page 125
Page 128
Page 136 f
Page 136
Page 139 ff
Page 145
Adaption of Section 4.1
New item C7 added
Comments added for items I6, I7, I8, I9, J11, J12
Item J1 updated
General test conditions noted for parameters K, L and M
BOM components C7, C8, L1, R2 and R3 updated
