TC1796
Summary of Features
1
Summary of Features
•
High-performance 32-bit super-scalar TriCore V1.3 CPU with 4-stage pipeline
– Superior real-time performance
– Strong bit handling
– Fully integrated DSP capabilities
– Single precision Floating Point Unit (FPU)
– 150 MHz operation at full temperature range
32-bit Peripheral Control Processor with single cycle instruction (PCP2)
– 16 Kbyte Parameter Memory (PRAM)
•
•
– 32 Kbyte Code Memory (CMEM)
Multiple on-chip memories
– 2 Mbyte Program Flash Memory (PFLASH) with ECC
– 128 Kbyte Data Flash Memory (DFLASH) usable for EEPROM emulation
– 136 Kbyte Data Memory (LDRAM, SRAM, SBRAM)
– 8 Kbyte Dual-Ported Memory (DPRAM)
– 48 Kbyte Code Scratchpad Memory (SPRAM)
– 16 Kbyte Instruction Cache (ICACHE)
– 16 Kbyte BootROM (BROM)
•
•
16-Channel DMA Controller
32-bit External Bus Interface Unit (EBU) with
– 75 dedicated address/data bus, clock, and control lines
– Synchronous burst Flash access capability
Sophisticated interrupt system with 2 × 255 hardware priority arbitration levels
serviced by CPU or PCP2
•
•
High performing on-chip bus structure
– Two 64-bit Local Memory Buses between EBU, Flash and Data Memory
– 32-bit System Peripheral Bus (SPB) for on-chip peripheral and functional units
– 32-bit Remote Peripheral Bus (RPB) for high-speed on-chip peripheral units
– Two bus bridges (LFI Bridge, DMA Controller)
Peripheral Control Processor with single cycle instruction (PCP2)
– 16 Kbyte Parameter Memory (PRAM)
•
•
– 32 Kbyte Code Memory (CMEM)
Versatile On-chip Peripheral Units
– Two Asynchronous/Synchronous Serial Channels (ASC) with baud rate generator,
parity, framing and overrun error detection
– Two High-Speed Synchronous Serial Channels (SSC) with programmable data
length and shift direction
– Two serial Micro Second Bus interfaces (MSC) for serial port expansion to external
power devices
– Two High-Speed Micro Link interfaces (MLI) for serial inter-processor
communication
