TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-5 Port 11 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

J15

P11.4

RFAST / General-purpose input

PU1 /

VFLEX /

GTM_TIM7_IN7_1

GTM_TIM4_IN2_5

GTM_TIM2_IN2_6

GETH_RXCLKB

P11.4

Mux input channel 7 of TIM module 7

Mux input channel 2 of TIM module 4

Mux input channel 2 of TIM module 2

Receive Clock MII

General-purpose output

GTM muxed output

GTM_TOUT121

ASCLIN3_ASCLK

—

Shift clock output

Reserved

—

Reserved

CAN13_TXD

GETH_TXER

GETH_TXCLK

P11.5

CAN transmit output node 3

Transmit Error MII

Transmit Clock Output for RGMII

General-purpose input

J13

SLOW /

RGMII_In

put / PU1

/ VFLEX /

GTM_TIM4_IN3_5

GTM_TIM2_IN3_8

GETH_TXCLKA

GETH_GREFCLK

Mux input channel 3 of TIM module 4

Mux input channel 3 of TIM module 2

Transmit Clock Input for MII

Gigabit Reference Clock input for RGMII (125 MHz high

precission)

P11.5

General-purpose output

GTM muxed output

Reserved

GTM_TOUT122

—

Reserved

—

Reserved

CAN20_TXD

CAN transmit output node 0

Reserved

—

Reserved

Data Sheet

V 1.2, 2021-03

OPEN MARKET VERSION
