SAK-TC399XP-256F300S BC 参数 Datasheet PDF下载

型号：	SAK-TC399XP-256F300S BC
PDF下载：	下载PDF文件查看货源
内容描述：	[Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontroller. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
分类和应用：
文件页数/大小：	548 页 / 21256 K
品牌：	INFINEON [ Infineon ]

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第50页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第51页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第52页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第53页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第55页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第56页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第57页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第58页

TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-4 Port 10 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

P10.8

SLOW /

PU1 /

VEXT /

General-purpose input

GTM_TIM4_IN0_13

GTM_TIM1_IN5_2

GTM_TIM0_IN5_2

CAN12_RXDB

GPT120_T4INB

QSPI3_SCLKB

SCU_E_REQ1_2

Mux input channel 0 of TIM module 4

Mux input channel 5 of TIM module 1

Mux input channel 5 of TIM module 0

CAN receive input node 2

Trigger/gate input of timer T4

Slave SPI clock inputs

ERU Channel 1 inputs 0 to 5 (0 is the LSB and 5 is the

MSB)

CCU60_CCPOS2C

Hall capture input 2

CAN receive input node 0

External RAMP B input

General-purpose output

GTM muxed output

Ready to send output

Master SPI clock output

Reserved

CAN20_RXDB

RIF1_RAMP1B

P10.8

GTM_TOUT110

ASCLIN2_ARTS

QSPI3_SCLK

—

Reserved

—

Reserved

—

Reserved

P10.9

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 0 of TIM module 6

Mux input channel 1 of TIM module 4

Mux input channel 1 of TIM module 0

Receive input channel 15

Receive input

GTM_TIM6_IN0_5

GTM_TIM4_IN1_4

GTM_TIM0_IN1_10

SENT_SENT15C

ASCLIN6_ARXD

P10.9

General-purpose output

GTM muxed output

Reserved

GTM_TOUT265

—

Reserved

Data Sheet

V 1.2, 2021-03

OPEN MARKET VERSION
