TC39x BC/BD-Step
Pin Definition and Functions: Sequence of Pads in Pad Frame
2.4
Sequence of Pads in Pad Frame
Table 2-63 Pad List
Number
Pad Name
Pad Type
X
Y
Comment
1
2
3
VEXT
VSS
Vx
Vx
255699
356499
175644
175644
175644
Supply Voltage
Supply Voltage
General-purpose I/O
P14.0
FAST / PU1 / 457299
VEXT / ES2
4
P15.7
FAST / PU1 / 558099
VEXT / ES
175644
General-purpose I/O
5
6
7
VDDP3
VDD
Vx
Vx
635499
714699
826200
322614
175644
322614
Supply Voltage
Supply Voltage
P15.10
LVDS_TX /
FAST / PU1 /
VEXT / ES6
General-purpose I/O
8
P15.11
LVDS_TX /
FAST / PU1 /
VEXT / ES6
920196
322614
General-purpose I/O
9
VSS
Vx
1031697
1143198
175644
322614
Supply Voltage
10
P15.12
LVDS_TX /
FAST / PU1 /
VEXT / ES6
General-purpose I/O
11
P15.13
LVDS_TX /
FAST / PU1 /
VEXT / ES6
1237194
322614
General-purpose I/O
12
13
P14.4
SLOW / PU2 / 1348695
VEXT / ES
175644
322614
General-purpose I/O
General-purpose I/O
P15.15
FAST / PU1 / 1395693
VEXT / ES
14
15
VDD
Vx
1463499
175644
322614
Supply Voltage
P15.14
FAST / PU1 / 1517499
VEXT / ES
General-purpose I/O
16
17
P14.3
SLOW / PU2 / 1564497
VEXT / ES
175644
322614
General-purpose I/O
General-purpose I/O
P14.11
SLOW / PU1 / 1611495
VEXT / ES
18
19
VSS
Vx
1665999
175644
322614
Supply Voltage
P14.1
FAST / PU1 / 1724499
VEXT / ES2
General-purpose I/O
20
21
22
P15.8
P14.13
VSS
FAST / PU1 / 1771497
VEXT / ES
175644
322614
175644
General-purpose I/O
General-purpose I/O
Supply Voltage
FAST / PU1 / 1818495
VEXT / ES
Vx
1865493
Data Sheet
376
V 1.2, 2021-03
