TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-292 Package Variant Pin Configuration

Table 2-43 Supply

Ball

Symbol

Ctrl. Buffer

Type

Function

P8, P13, N7, VDD

N14, E15,

H14, D16,

G13

—

Digital Core Power Supply (1.25V)

A2, B3, V19, VEXT

W20

—

External Power Supply (5V / 3.3V)

VFLEX

VDDM

VDDP3

—

Digital Power Supply for Flex Port Pads (5V / 3.3V)

ADC Analog Power Supply (5V / 3.3V)

Flash Power Supply (3.3V)

B18, A19

B2, D4, E5, VSS

T16, U17,

Digital Ground

W19, Y20,

E16, D17,

B19, A20

VSSM

—

Analog Ground for VDDM

Digital Ground

P9, P12, N9, VSS

N10, N11,

N12, M7,

M8, M10,

M11, M13,

M14, L8, L9,

L10, L11,

L12, L13,

K8, K9, K10,

K11, K12,

K13, J7, J8,

J10, J11,

J13, J14, H9,

H10, H11,

H12, G9,

G12

L20

VSS

—

Oscillator Ground, VSS(OSC)

VAREF1

VAGND1

VAREF2

VAGND2

NC1

Positive Analog Reference Voltage 1

Negative Analog Reference Voltage 1

Positive Analog Reference Voltage 2

Negative Analog Reference Voltage 2

A1, Y1, U4

Not connected. These pins are not connected on

package level and will not be used for future

extensions

G8, H7

VDDSB (VDD)

—

Devices with integrated EMEM: EMEM SRAM Standby

Power Supply, VDDSB (1.25V); Devices without

integrated EMEM: VDD (1.25V)

Data Sheet

275

V 1.2, 2021-03

OPEN MARKET VERSION
