TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-292 Package Variant Pin Configuration

Table 2-38 Port 32 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

W17

P32.1

SLOW /

PU1 /

VEXT /

General-purpose input

P32.1 / External Pass Device gate control for EVRC

GTM_TIM3_IN3_15

Mux input channel 3 of TIM module 3

General-purpose output

GTM muxed output

Reserved

P32.1

GTM_TOUT37

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

Y18

P32.2

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 3 of TIM module 1

Mux input channel 3 of TIM module 0

CAN receive input node 3

Receive input

GTM_TIM1_IN3_8

GTM_TIM0_IN3_8

CAN03_RXDB

ASCLIN3_ARXD

CAN21_RXDD

P32.2

CAN receive input node 1

General-purpose output

GTM muxed output

Transmit output

GTM_TOUT38

ASCLIN3_ATX

IOM_MON2_15

IOM_REF2_15

—

Monitor input 2

Reference input 2

Reserved

—

Reserved

—

Reserved

PMS_DCDCSYNCO

—

DC-DC synchronization output

Reserved

Data Sheet

248

V 1.2, 2021-03

OPEN MARKET VERSION
