SAK-TC399XP-256F300S BC 参数 Datasheet PDF下载

SAK-TC399XP-256F300S BC图片预览
型号: SAK-TC399XP-256F300S BC
PDF下载: 下载PDF文件 查看货源
内容描述: [Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontrol­ler. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
分类和应用:
文件页数/大小: 548 页 / 21256 K
品牌: INFINEON [ Infineon ]
 浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第240页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第241页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第242页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第243页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第245页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第246页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第247页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第248页
TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-292 Package Variant Pin Configuration
Table 2-37 Port 23 Functions
Ball
Symbol
Ctrl. Buffer
Type
Function
V20
P23.0
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 7 of TIM module 6
Mux input channel 5 of TIM module 1
Mux input channel 5 of TIM module 0
CAN receive input node 0
General-purpose output
GTM muxed output
GTM_TIM6_IN7_1
GTM_TIM1_IN5_4
GTM_TIM0_IN5_4
CAN10_RXDC
P23.0
O0
O1
O2
O3
O4
O5
O6
O7
I
GTM_TOUT41
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
U19
P23.1
FAST /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 6 of TIM module 6
Mux input channel 6 of TIM module 1
Mux input channel 6 of TIM module 0
Upstream assynchronous input signal
Receive input
GTM_TIM6_IN6_1
GTM_TIM1_IN6_4
GTM_TIM0_IN6_4
MSC1_SDI0
ASCLIN6_ARXF
P23.1
O0
O1
O2
O3
O4
O5
O6
O7
General-purpose output
GTM muxed output
GTM_TOUT42
ASCLIN1_ARTS
QSPI4_SLSO6
GTM_CLK0
CAN10_TXD
CCU_EXTCLK0
ASCLIN6_ASCLK
Ready to send output
Master slave select output
CGM generated clock
CAN transmit output node 0
External Clock 0
Shift clock output
Data Sheet
244
V 1.2, 2021-03
OPEN MARKET VERSION
