TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-292 Package Variant Pin Configuration

Table 2-26 Port 01 Functions

Ball

Symbol

Ctrl. Buffer

Type

Function

P01.3

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 5 of TIM module 4

Mux input channel 0 of TIM module 2

Mux input channel 5 of TIM module 0

Slave select input

GTM_TIM4_IN5_2

GTM_TIM2_IN0_14

GTM_TIM0_IN5_8

QSPI3_SLSIB

EDSADC_ITR7F

EVADC_G9CH14

P01.3

Trigger/Gate input, channel 7

Analog input channel 14, group 9

General-purpose output

GTM muxed output

GTM_TOUT111

—

Reserved

—

Reserved

QSPI3_SLSO9

CAN01_TXD

IOM_MON2_6

IOM_REF2_6

—

Master slave select output

CAN transmit output node 1

Monitor input 2

Reference input 2

Reserved

—

Reserved

P01.4

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 6 of TIM module 4

Mux input channel 1 of TIM module 2

Mux input channel 6 of TIM module 0

CAN receive input node 1

Trigger/Gate input, channel 7

Analog input channel 13, group 9

General-purpose output

GTM muxed output

GTM_TIM4_IN6_2

GTM_TIM2_IN1_14

GTM_TIM0_IN6_8

CAN01_RXDC

EDSADC_ITR7E

EVADC_G9CH13

P01.4

GTM_TOUT112

—

Reserved

ASCLIN9_ASLSO

QSPI3_SLSO10

—

Slave select signal output

Master slave select output

Reserved

—

Reserved

—

Reserved

Data Sheet

185

V 1.2, 2021-03

OPEN MARKET VERSION
