CoolSET®-F3R
ICE3BR4765J
Typical CoolMOS® Performance Characteristic
5
Typical CoolMOS® Performance Characteristic
Safe Operating Area for ICE3A(B)R4765J
ID = f ( VDS
)
parameter : D = 0, TC = 25deg.C
10
1
0.1
tp = 0.1ms
tp = 1ms
tp = 10ms
tp = 100ms
tp = 1000ms
DC
0.01
0.001
1
10
100
1000
VDS [V]
Figure 27
Safe Operating area (SOA) curve for ICE3BR4765J
SOA temperature derating coefficient curve
( package dissipation ) for F3 & F2 CoolSET
120
100
80
60
40
20
0
0
20
40
60
80
100
120
140
Ambient/Case temperature Ta/Tc [deg.C]
Ta : DIP, Tc : TO220
Figure 28
SOA temperature derating coefficient curve
Version 2.5
24
19 Nov 2012
