CoolSET®-F3R
ICE3BR4765J
Electrical Characteristics
4.2
Operating Range
Note: Within the operating range the IC operates as described in the functional description.
Parameter
Symbol
Limit Values
Unit
Remarks
min.
max.
25
VCC Supply Voltage
VVCC
TjCon
VVCCoff
-25
V
Max value limited due to Vcc OVP
Junction Temperature of
Controller
130
°C
Max value limited due to thermal
shut down of controller
Junction Temperature of
CoolMOS®
TjCoolMOS
-25
150
°C
4.3
Characteristics
4.3.1
Supply Section
Note: The electrical characteristics involve the spread of values within the specified supply voltage and junction
temperature range TJ from – 25 °C to 125 °C. Typical values represent the median values, which are
related to 25°C. If not otherwise stated, a supply voltage of VCC = 18 V is assumed.
Parameter
Symbol
Limit Values
Unit
Test Condition
min.
typ.
max.
Start Up Current
IVCCstart
-
150
250
μA
VVCC =17V
VCC Charge Current
IVCCcharge1
-
-
5.0
1.60
-
mA
mA
mA
μA
VVCC = 0V
VVCC = 1V
VVCC =17V
IVCCcharge2 0.55
0.9
0.7
0.2
IVCCcharge3
IStartLeak
-
-
Leakage Current of
50
VDrain = 450V
at Tj=100°C
Start Up Cell and CoolMOS®
Supply Current with
Inactive Gate
IVCCsup1
-
1.5
2.5
mA
Supply Current with Active Gate
IVCCsup2
-
-
2.5
3.4
-
mA
IFB = 0A
IFB = 0A
Supply Current in
Auto Restart Mode with Inactive
Gate
IVCCrestart
250
μA
Supply Current in Active Burst
Mode with Inactive Gate
IVCCburst1
IVCCburst2
-
-
450
450
950
950
μA
μA
VFB = 2.5V
VVCC = 11.5V,VFB = 2.5V
VCC Turn-On Threshold
VCC Turn-Off Threshold
VCC Turn-On/Off Hysteresis
VVCCon
VVCCoff
VVCChys
17.0
9.8
-
18.0
10.5
7.5
19.0
11.2
-
V
V
V
Version 2.5
20
19 Nov 2012
