BTS7012-2EPA
PROFET™ +2 12V
Application Information
10
Application Information
Note:
10.1
The following information is given as a hint for the implementation of the device only and shall not
be regarded as a description or warranty of a certain functionality, condition or quality of the device.
Application Setup
VBAT
ZWIRE
Optional
Optional
CVSGND
CVS
RGND
T1
Logic Supply
VDD
GND
VS
GPIO
RIN
RIN
IN0
IN1
GPIO
GPIO
GPIO
OUT0
RDEN
RDSEL
DEN
DSEL
COUT0
PROFET™ +2
12V
Microcontroller
DZ2
CVS2
OUT1
ADC
VSS
RADC
RIS_PROT
IS
COUT1
CSENSE
DZ1
Logic GND
Power GND
Optional
Chassis GND
*See Chapter 1 „Potential Applications“
App_2CH_INTD IO_CVG_LO.emf
Figure 43 BTS7012-2EPA Application Diagram
Note:
This is a very simplified example of an application circuit. The function must be verified in the real
application.
Table 23 Loads considered for Reverse Polarity setup (see P_4.1.0.5)
Output
RDS(ON),max @ TJ = 150 °C
Load connected
12 mΩ
21.5 mΩ
H4_55W
Data Sheet
54
Rev. 1.10
2020-12-14
