■Crimp Contact for socket
For AWG# 14 to 16
For AWG# 10 to 12
4.7
2.8
4.7
3.8
3.8
2.8
P=16.5
t=0.4
P=15.5
t=0.3
Applicable cable
Part Number
CL No.
Packaging
Quantity
UL style
1430
Jacket diameter
Wire size
Stranded wire conductor
Reel
Bag
Reel
Bag
Reel
Bag
DF22-1416SCF
DF22-1416SC
680-1000-3
680-1001-6
680-1002-9
680-1003-1
680-1089-7
680-1090-6
2,500
100
2.4 to 3.0
AWG#16
AWG#14
26/0.254
41/0.26
DF22A-1416SCF
DF22A-1416SC
DF22A-1012SCF
DF22A-1012SC
2,000
100
3.0 to 3.8
3.6 to 4.9
1015
AWG#12
AWG#10
65/0.26
2,000
100
104/0.26
Note 1: Applicable wire with tin plated solid soft conductor.
Note 2: When using other than the recommended wire, contact your nearest Hirose representative.
Note 3: Strip length: 3.5 to 4.5mm
■Crimp Contact
for In-line Plug
4.7
3.8
2.8
1.6
0.8
1416
P=15.5
t=0.3
Applicable cable
Part Number
CL No.
Packaging
Quantity
UL style
1430
Jacket diameter
Wire size
Stranded wire conductor
Reel
Bag
Reel
Bag
DF22-1416PCF
DF22-1416PC
DF22A-1416PCF
DF22A-1416PC
680-1078-0
680-1080-2
680-1079-3
680-1081-5
2,500
100
2.4 to 3.0
3.0 to 3.8
AWG#16
AWG#14
26/0.254
41/0.26
2,000
100
1015
Note 1: Applicable wire with tin plated solid soft conductor.
Note 2: When using other than the recommended wire, contact your nearest Hirose representative.
Note 3: Strip length: 3.5 to 4.5mm
