GPRS Electrical Characteristics
Test conditions Vdd= +3.5V, a pulse width of 1154 µs and a duty cycle of 25% at a case temperature of +25°C unless otherwise stated.
Psat: Pin = 0 dBm; Vapc = 2.2V
Pout (dBm)
880 MHz
PAE (%)
880 MHz
900 MHz
915 MHz
900 MHz
915 MHz
Class 8 (1-slot)
Class 10 (2-slot)
Class 12 (4-slot)
35.18
35.15
35.16
35.40
35.45
35.32
35.40
35.43
35.36
60.23
60.07
60.09
60.47
61.02
59.62
59.55
59.77
59.35
Psat: Pin = 0 dBm; Vapc = 2.2V
Pout (dBm)
PAE (%)
1710 MHz
1750 MHz
1785 MHz
1710 MHz 1750 MHz
1785 MHz
Class 8 (1-slot)
Class 10 (2-slot)
Class 12 (4-slot)
33.00
33.00
33.00
33.08
33.08
33.08
33.12
33.10
33.10
59.00
59.35
59.35
59.19
59.42
59.42
59.62
59.40
59.40
Psat: Pin = 0 dBm; Vapc = 2.2V
Pout (dBm)
PAE (%)
1850 MHz
1880 MHz
1910 MHz
1850 MHz 1880 MHz
1910 MHz
Class 8 (1-slot)
Class 10 (2-slot)
Class 12 (4-slot)
33.10
33.10
33.10
33.10
33.10
33.04
33.02
33.02
32.96
59.14
59.14
58.75
58.93
58.93
58.50
58.66
58.66
58.25
5
