Performance Characteristics (continued)
Storage
Save/Recall (non-volatile)
Floppy Disk
54621A/D, 54622A/D, 54624A: 3 setups and traces can be saved and recalled internally
54641A/D, 54642A/D: 4 setups and traces can be saved and recalled internally
3.5” 1.44 MB double density
Image formats : TIF, BMP
Data formats: X and Y (time/voltage) values in CSV format
Trace/setup formats: Recalled
I/O
RS-232 (Serial) Standard Port
Parallel Standard Port
Printer Compatibility
1 port: XON or DTR; 8 data bits; 1 stop bit; parity = none; 9600, 19200, 38400, 57600 baud rates (use Agilent 34398A cable)
Printer support
HP DeskJet, LaserJet with HP PCL 3 or greater compatibility:
Black and white @150x150 dpi; Gray scale @ 600x600 dpi
Epson: black and white @180x180 dpi
Seiko thermal DPU-414: black and white
Optional GPIB Interface
Module (N2757A)
Fully programmable with IEEE488.2 compliance
Typical GPIB throughput of 20 measurements or twenty 2000-point records per second
Optional Printer Kit
The N2727A is a thermal printer kit, includingprinter power, parallel cable, power cable and paper
General Characteristics
Physical
Size: 32.26 cm wide x 17.27 cm high x 31.75 cm deep (without handle)
Weight: 6.35 kgs (14 lbs) on 54621A/D, 54622A/D, 54624A; 6.82 kgs (15 lbs) on 54641A/D, 54642A/D
Probe Comp Output
Trigger Out
54621A/D, 54642A/D, 54624A: Frequency ~1.2 kHz; Amplitude ~5 V
54641A/D, 54642A/D: Frequency ~2 kHz; Amplitude ~5 V
54621A/D, 54622A/D, 54624A: 0 to 5 V with 50 Ω source impedance; delay ~ 55 ns
54641A/D, 54642A/D: 0 to 5 V with 50 Ω source impedance; delay ~ 22 ns
Printer Power
7.2 to 9.2 V, 1 A
Kensington lock
Connection on rear panel for security
*
Denotes Warranted Specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and ± 10 ꢀC from firmware calibration temperature.
