Probes
To get the most out of your scope,
you need the right probes and
accessories for your particular
application. That's why Agilent
Technologies offers a complete
family of innovative probes and
54600-Series scopes. For more
comprehensive information,
please see the Agilent
54600-Series Oscilloscopes
Probes and Accessories
data sheet (Agilent publication
number 5968-8153). You can get a
copy by visiting our website at:
www.agilent.com/find/mso
Agilent Passive Probes Selection Guide
10070C
10073C (shipped
10074C (shipped
10076A
N2771A
with 54640-Series)
with 54620-Series)
high-voltage probe
high-voltage probe
Probe Bandwidth
20 MHz
< 17.5 ns
1:1
500 MHz
< 700 ps
10:1
150 MHz
< 2.33 ns
10:1
250 MHz
< 1.4 ns
100:1
50 MHz
< 7 ns
Probe Risetime (Calculated)
Attenuation Ratio
1000:1
100 MΩ
Input Resistance
1 MΩ
2.2 MΩ
10 MΩ
66.7 MΩ
(when terminated into 1 MΩ)
Input Capacitance
Approx. 70 pF
Approx. 12 pF
Approx. 15 pF
Approx. 3 pF
4000 Vpk
Approx. 1 pF
Maximum Input
(dc + peak ac)
400 Vpk CAT I
(mains isolated)
400 Vpk CAT II
(post receptacle
mains)
500 Vpk CAT I
(mains isolated)
400 Vpk CAT II
(post receptacle
mains)
500 Vpk CAT I
(mains isolated)
400 Vpk CAT II
(post receptacle
mains)
15 kV dc, 10 kVrms
30 kV dc + peak ac
Compensation Range
Probe Sense
None
No
6 - 15 pF
Yes
9 - 17 pF
Yes
6 - 20 pF
Yes
7 - 25 pF
No
Current Probes
Description
1146A
100 kHz current probe, ac/dc
50 MHz current probe, ac/dc
power supply for N2774A
N2774A
N2775A
Differential Probes
Description
N2772A
N2773A
20 MHz differential probe
Differential probe power supply
