Triggering
Figure 6. Make your automotive and industrial testing easier.
CAN triggering synchronizes to the start of a CAN frame on any
CAN high or CAN low signal.
Figure 5. Easily synchronize to a
USB packet.
USB is quickly becoming the
Flexible Triggering
CAN, LIN, and USB Triggering
connection of choice for PC
peripherals. Make your testing
easy with Start of Packet (SOP),
End of Packet (EOP), Reset
Complete (RC), Enter Suspend,
or Exit Suspend modes.
With mixed analog and digital
designs, sometimes it is hard to
trace an anomaly back to its root
cause unless you can trigger on it
and correlate it with another
signal. With the 54600-Series
scopes, triggering is no longer a
hassle. They come with flexible
triggering capabilities across all
channels so you can easily isolate
and analyze complex signals and
interactions common in your
mixed analog and digital designs.
Controller Area Network (CAN)
and Universal Serial Bus (USB)
triggering comes standard with
the 54600-Series scopes. These
triggering modes make it easy to
synchronize CAN, LIN, and USB
frames. Don’t waste time finding
the start of the complex frames –
let Agilent do it for you.
The N2758A CAN trigger module
option enables the MSO to isolate
and trigger on a particular
frame’s content. For more
information , see page 7.
CAN triggering synchronizes to
the start of a CAN frame on any
CAN high or CAN low signal.
Trigger on LIN (local interconnect
network) sync break at the begin-
ning of a message frame.
8
