Encoder Detectors
HLC2701
HLC2705
Type
side-looking
side-looking
Output option
Resolution
speed/direction (A-B output)
0,03 mm [0.009 in]
pc mount
speed/direction (tach output)
0,46 mm [0.018 in]
pc mount
Package style (plastic)
Tach pulse width
–
3 ms to 20 ms
Tach pulse level, active
Output rise/fall time
Supply voltage
0.4 V
–
100 ns
–
4.5 V to 5.5 V
through-hole
0.020 in sq leads
4.5 V to 5.5 V
through-hole
0.020 in sq leads
Mounting configuration
Termination style
Transmissive
Encoders
HOA0901
HOA0902
Type
sensor
sensor
Output option
speed/direction (A-B output)
speed/direction (tach output)
Resolution
0,03 mm [0.009 in]
0,46 mm [0.018 in]
Package style (transmissive)
Tach pulse width
pc mount
pc mount
–
3 ms to 20 ms
Tach pulse level, active
Output rise/fall time
Infrared emitter trigger current
Supply voltage
–
0.4 V
100 ns
–
<15 mA
<15 mA
4.5 V to 5.5 V
4.5 V to 5.5 V
Mounting configuration
Termination style
dual mounting tabs (-012 or no tab pcb mount) (-011)
0.020 in sq leads
dual mounting tabs (-012 or no tab pcb mount) (-011)
0.020 in sq leads
www.honeywell.com/sensing
9
