HT36F2
Instruction Definition
ADC A,[m]
Add data memory and carry to the accumulator
Description
The contents of the specified data memory, accumulator and the carry flag are added si-
multaneously, leaving the result in the accumulator.
Operation
ACC ¬ ACC+[m]+C
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
Ö
Ö
Ö
Ö
ADCM A,[m]
Add the accumulator and carry to data memory
Description
The contents of the specified data memory, accumulator and the carry flag are added si-
multaneously, leaving the result in the specified data memory.
Operation
[m] ¬ ACC+[m]+C
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
Ö
Ö
Ö
Ö
ADD A,[m]
Add data memory to the accumulator
Description
The contents of the specified data memory and the accumulator are added. The result is
stored in the accumulator.
Operation
ACC ¬ ACC+[m]
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
Ö
Ö
Ö
Ö
ADD A,x
Add immediate data to the accumulator
Description
The contents of the accumulator and the specified data are added, leaving the result in the
accumulator.
Operation
ACC ¬ ACC+x
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
Ö
Ö
Ö
Ö
ADDM A,[m]
Add the accumulator to the data memory
Description
The contents of the specified data memory and the accumulator are added. The result is
stored in the data memory.
Operation
[m] ¬ ACC+[m]
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
Ö
Ö
Ö
Ö
Rev. 1.00
19
August 15, 2005
