Function Diagram:
HAZARDOUS AREA ZONE 0 (ZONE 20) GROUP IIC,
SAFE AREA, ZONE 2 GROUP IIC T4,
NON HAZARDOUS LOCATIONS, CLASS I, DIVISION 2,
GROUPS A, B, C, D T-Code T4, CLASS I, ZONE 2, GROUP IIC T4
HAZARDOUS LOCATIONS CLASS I, DIVISION 1, GROUPS A, B, C, D,
CLASS II, DIVISION 1, GROUPS E, F, G, CLASS III, DIVISION 1,
CLASS I, ZONE 0, GROUP IIC
Safety Description
Terminals 14-11
(with 15-12 shorted)
Uo/Voc = 27.4 V
Io/Isc = 91 mA
Po/Po = 624 mW
Group Co/Ca Lo/La
Lo/Ro
Cenelec (µF) (mH) (µH/Ω)
IIC
IIB
IIA
0.085
0.675
2.258
4.3
17.2
34.5
54.7
218.9
437.9
MODEL D1010D Duplicator
3 +
=
=
Supply 24 Vdc
Out 1-A
4 -
=
HHT
HHT
+
2 Wire Tx
Source I
Source V
14
1
2
8
+
-
+
-
?
Sink I
=
mA RL
In 1
15
16
+
-
V
RL
I
+
-
mA
=
=
=
Out 1-B
=
Source I
Source V
10
11
12
5
6
7
+
-
+
-
Sink I
=
mA RL
+
-
V
RL
+
mA
=
Connections for Duplication of 2 wires Transmitter Input
Restriction on specifications for 2 wires Transmitter Input:
Bidirectional communication for Smart Transmitter is provided only on channel 1
The minimum supply voltage available for Transmitter (Vtx) is 14.1 V at 20 mA input
The safety parameters must be changed in: Uo/Voc = 27.4 V, Io/Isc = 91 mA, Po/Po = 624 mW
