MB1504
MB1504H
MB1504L
RECOMMENDED OPERATING CONDITIONS
Value
Typ
Parameter
Symbol
Unit
Min
Max
V
2.7
3.0
—
—
—
5.5
—
V
CC
Power Supply Voltage
V
MB1504H
V
CC
10.0
8.5
PH
V
V
MB1504
MB1504L
V
CC
V , V
P
PL
V
OOPH
MB1504H
V
10.0
8.5
CC
CC
Open-drain Output
MB1504
MB1504L
V
, V
V
—
—
OOP OOPL
—
—
Input Voltage
V
GND
–40
V
CC
V
IN
Operating Temperature
T
+85
—
°C
A
HANDLING PRECAUTIONS
• This device should be transported and stored in anti-static containers.
• This is a static-sensitive device; take proper anti-ESD precautions. Ensure that personnel and equipment are properly grounded. Cover work-
benches with grounded conductive mats.
• Always turn the power supply off before inserting or removing the device from its socket.
• Protect leads with a conductive sheet when handling or transporting PC boards with devices.
