D A T A S H E E T
PRODUCT SELECTOR GUIDE
Family Part Number
Am29LV010B
-70
Speed Options
Full Voltage Range: VCC = 2.7–3.6 V
-55
-90
90
90
35
Max access time, ns (tACC
)
55
55
30
70
70
30
Max CE# access time, ns (tCE
)
Max OE# access time, ns (tOE
)
Note:See “AC Characteristics” for full specifications.
BLOCK DIAGRAM
DQ0–DQ7
VCC
VSS
Sector Switches
Erase Voltage
Generator
Input/Output
Buffers
State
Control
WE#
Command
Register
PGM Voltage
Generator
Data
Latch
Chip Enable
Output Enable
Logic
STB
CE#
OE#
Y-Decoder
X-Decoder
Y-Gating
STB
VCC Detector
Timer
Cell Matrix
A0–A16
6
Am29LV010B
22140D6 October 11, 2006
