Ordering Information
Table 19. Susceptibility Performance Classification (continued)
Performance Criteria
Result
The MCU does not perform as designed during exposure. The MCU does not return to
normal operation until exposure is removed and the power to the MCU is cycled.
D
Hard failure
Damage
The MCU does not perform as designed during and after exposure. The MCU cannot
be returned to proper operation due to physical damage or other permanent
performance degradation.
E
4
Ordering Information
This section contains ordering information for the device numbering system.
Example of the device numbering system:
8
C
XX
MC 9 S08 QE
Status
(MC = Fully Qualified)
Package designator (see Table 20)
Temperature range
(C = –40°C to 85°C)
Memory
(9 = Flash-based)
Core
Approximate flash size in Kbytes
Family
5
Package Information
Table 20. Package Descriptions
Pin Count
Package Type
Abbreviation
Designator
Case No.
Document No.
32
28
20
16
16
Low Quad Flat Package
LQFP
SOIC
LC
WL
WJ
PG
TG
873A
751F
751D
648
98ASH70029A
98ASB42345B
98ASB42343B
98ASB42431B
98ASH70247A
Small Outline Integrated Circuit
Small Outline Integrated Circuit
Plastic Dual In-line Package
Thin Shrink Small Outline Package
SOIC
PDIP
TSSOP
948F
5.1
Mechanical Drawings
The following pages are mechanical drawings for the packages described in Table 20.
MC9S08QE8 Series, Rev. 3
Freescale Semiconductor
Preliminary
29
Subject to Change Without Notice
