Functional Description
5.3.2
Interrupt Nesting
Interrupt exceptions may be nested to allow an IRQ of higher priority than the current exception to be
serviced. The following tables define the nesting requirements for each priority level.
Table 5-1 Interrupt Mask Bit Definition
SR[9]1
SR[8]1
Permitted Exceptions
Masked Exceptions
None
0
0
1
1
0
1
0
1
Priorities 0, 1, 2, 3
Priorities 1, 2, 3
Priorities 2, 3
Priority 3
Priority 0
Priorities 0, 1
Priorities 0, 1, 2
1. Core status register bits indicating current interrupt mask within the core.
Table 5-2. Interrupt Priority Encoding
Current Interrupt
Priority Level
Required Nested
Exception Priority
IPIC_LEVEL[1:0]1
00
01
10
11
No Interrupt or SWILP
Priority 0
Priorities 0, 1, 2, 3
Priorities 1, 2, 3
Priorities 2, 3
Priority 3
Priority 1
Priorities 2 or 3
1. See IPIC field definition in Part 5.6.30.2
5.3.3
Fast Interrupt Handling
Fast interrupts are described in the DSP56F800E Reference Manual. The interrupt controller recognizes
fast interrupts before the core does.
A fast interrupt is defined (to the ITCN) by:
1. Setting the priority of the interrupt as level 2, with the appropriate field in the IPR registers
2. Setting the FIMn register to the appropriate vector number
3. Setting the FIVALn and FIVAHn registers with the address of the code for the fast interrupt
When an interrupt occurs, its vector number is compared with the FIM0 and FIM1 register values. If a
match occurs, and it is a level 2 interrupt, the ITCN handles it as a fast interrupt. The ITCN takes the vector
address from the appropriate FIVALn and FIVAHn registers, instead of generating an address that is an
offset from the VBA.
The core then fetches the instruction from the indicated vector adddress and if it is not a JSR, the core starts
its fast interrupt handling.
