5.6.30 ITCN Control Register (ICTL)
Base + $1D
Read
15
14
13
12 11 10
9
8
7
6
0
5
INT_DIS
0
4
1
3
2
1
0
INT
IPIC
VAB
IRQB STATE IRQA STATE
IRQB IRQA
EDG
EDG
Write
0
0
0
1
0
0
0
0
0
1
1
1
0
0
RESET
Figure 5-26 ITCN Control Register (ICTL)
5.6.30.1 Interrupt (INT)—Bit 15
This read-only bit reflects the state of the interrupt to the 56800E core.
•
•
0 = No interrupt is being sent to the 56800E core
1 = An interrupt is being sent to the 56800E core
5.6.30.2 Interrupt Priority Level (IPIC)—Bits 14–13
These read-only bits reflect the state of the new interrupt priority level bits being presented to the 56800E
core at the time the last IRQ was taken. This field is only updated when the 56800E core jumps to a new
interrupt service routine.
Note:
Nested interrupts may cause this field to be updated before the original interrupt service routine can
read it.
•
•
•
•
00 = Required nested exception priority levels are 0, 1, 2, or 3
01 = Required nested exception priority levels are 1, 2, or 3
10 = Required nested exception priority levels are 2 or 3
11 = Required nested exception priority level is 3
5.6.30.3 Vector Number - Vector Address Bus (VAB)—Bits 12–6
This read-only field shows the vector number (VAB[7:1]) used at the time the last IRQ was taken. This
field is only updated when the 56800E core jumps to a new interrupt service routine.
Note:
Nested interrupts may cause this field to be updated before the original interrupt service routine can
read it.
5.6.30.4 Interrupt Disable (INT_DIS)—Bit 5
This bit allows all interrupts to be disabled.
•
•
0 = Normal operation (default)
1 = All interrupts disabled
5.6.30.5 Reserved—Bit 4
This bit field is reserved or not implemented. It is read as 1 and cannot be modified by writing.
