Because of the low duty cycle on most device pins, power dissipation due to capacitive loads was found
to be fairly low when averaged over a period of time.
E, the external [static component], reflects the effects of placing resistive loads on the outputs of the
2
device. Sum the total of all V /R or IV to arrive at the resistive load contribution to power. Assume V = 0.5
for the purposes of these rough calculations. For instance, if there is a total of eight PWM outputs driving
10mA into LEDs, then P = 8*.5*.01 = 40mW.
In previous discussions, power consumption due to parasitics associated with pure input pins is ignored,
as it is assumed to be negligible.
