ELECTRICAL CHARACTERISTICS
MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
MAXIMUM RATINGS
Table 2. Maximum Ratings
All voltages are with respect to ground unless otherwise noted. Exceeding these ratings may cause a malfunction or
permanent damage to the device.
Ratings
Symbol
Value
Unit
ELECTRICAL RATINGS
VB+ Supply Voltage
VCC Voltage
VVB+
45
7.0
1.5
V
V
A
V
V
V
CC(MAX)
Bridge Output Current
Maximum Voltage on RESET
I
OUT
(1)
V
V
- 0.5
CC
MAXRST
ESD Voltage (2)
Human Body Model
Machine Model
V
V
±1000
±100
ESD1
ESD2
THERMAL RATINGS
Storage Temperature
T
-40 to 175
0 to 70
135
°C
°C
STG
Operating Ambient Temperature
Operating Junction Temperature
T
A
T
P
°C
J
Power Dissipation (T = 25° C) (3)
2.0
W
A
D
Pin Soldering Temperature (4)
T
220
°C
SOLDER
Thermal Resistance, Junction to Ambient (5)
R
37
°C/W
θJA
Notes
1. RESET is an open drain (open collector) output with an internal pull-up resistor.
2. ESD testing is performed in accordance with the Human Body Model (HBM) (CZAP = 100 pF, RZAP = 1500 Ω), the Machine Model (MM)
(CZAP = 200 pF, RZAP = 0 Ω), and the Charge Device Model (CDM), Robotic (CZAP = 4.0pF).
3. Maximum power dissipation at indicated ambient temperature in free air with no heatsink used.
4. Pin soldering temperature limit is for 10 seconds maximum duration. Not designed for immersion soldering. Exceeding these limits may
cause malfunction or permanent damage to the device.
5.
R
is dependent on customer application and PCB layout.
θJA
34920
Analog Integrated Circuit Device Data
Freescale Semiconductor
5
