F71872
3-2 GPIO5_PW_SEL
1-0 GPIO4_PW_SEL
R/W
R/W
00
00
GPIO5 pulse width select:
00: 500us (default).
01: 1ms.
10: 20ms.
11: 100ms.
GPIO4 pulse width select:
00: 500us (default).
01: 1ms.
10: 20ms.
11: 100ms.
7.8.2.8 GPIO Pulse Mode Register Index E6h
Bit
Name
R/W Default
Description
7
Reserved
-
-
Reserved.
6
GPIO6_PUL_MODE R/W
GPIO5_PUL_MODE R/W
GPIO4_PUL_MODE R/W
GPIO3_PUL_MODE R/W
GPIO2_PUL_MODE R/W
GPIO1_PUL_MODE R/W
GPIO0_PUL_MODE R/W
0
GPIO6 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
5
4
3
2
1
0
0
0
0
0
0
0
GPIO5 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
GPIO4 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
GPIO3 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
GPIO2 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
GPIO1 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
GPIO0 pulse mode:
0: output low pulse when in pulse mode.
1: output high pulse when in pulse mode.
7.8.2.9 GPIO Pad Type Register Index E7h
Bit
7
Name
Reserved
R/W Default
Description
-
-
Reserved.
6
GPIO6_DRV_EN
R/W
0
GPIO6 pad type:
0: open drain.
1: push-pull.
5
GPIO5_DRV_EN
R/W
0
GPIO5 pad type:
0: open drain.
1: push-pull.
