J2000 SERIES/J2200
Receptacle housing (Side locking type)
Circuits Keying
Model No.
Q’ty / bag
10
Line No.
2.5
X
J22DF-10V-KX
J22DF-10V-KY
250
250
10
A
B
Y
Material
Glass-filled PBT, UL94V-0, black
RoHS compliance
17.8
Keying No.
Series name
X
J–2
1
2 3 4 5
Circuit No.
(26.4)
Header Side entry type (Side locking type)
Circuits Keying
Model No.
Q’ty / box
±0.05
15
10
±0.05
±0.05
±0.05
2.5
X
S10B-J22DK-GGXR
S10B-J22DK-GGYR
120
120
10
2.5
Y
Circuit No.
Keying No.
+0.05
–0.03
10-φ0.85
Material and Finish
Tab contact: Copper alloy, nickel-undercoated, selective gold-plated
Housing: Glass-filled PBT, UL94V-0, black
Series
name
1
2 3 4 5
X
Through-hole
±0.05
2-φ2
Reinforcing metal fixture: Copper alloy, nickel-undercoated, selective gold-plated
Copper foil land
J - 2 2 0 0
RoHS compliance This product displays (LF)(AU) on a label.
2
-(φ3.4)
Connector
outline
(20.4)
PC board layout
(viewed from component side)
20.4
17.8
B
A
Line No.
2.5
2.5
10
(3.23)
(7.68)
(7)
2.5
(15)
8
