ZSPM1025A
True Digital PWM Controller (Single-Phase, Single-Rail)
5.2.6.
Typical Load Transient Response – Capacitor Range #2 – VOUT Range #2
Test conditions: VIN = 12.0V, VOUT = 1.80V
Minimum output capacitance: 3 x 100µF/6.3V X5R + 2 x 47µF/10V X7R
Maximum output capacitance: 7 x 100µF/6.3V X5R + 4 x 47µF/10V X7R
Figure 5.27 5 to 20A Load Step – Min. Capacitance
Figure 5.28 20 to 5A Load Step – Min. Capacitance
Ch1 (Blue): VOUT 50mV/div AC
Ch2 (Cyan): PWM 5V/div DC
Ch3: (Violet): Load Trigger 5V/div DC
Time Scale: 8µs/div
Ch1 (Blue): VOUT 50mV/div AC
Ch2 (Cyan): PWM 5V/div DC
Ch3: (Violet): Load Trigger 5V/div DC
Time Scale: 8µs/div
Figure 5.29 5 to 20A Load Step – Max. Capacitance
Figure 5.30 20 to 5A Load Step – Max. Capacitance
Ch1 (Blue): VOUT 50mV/div AC
Ch2 (Cyan): PWM 5V/div DC
Ch3: (Violet): Load Trigger 5V/div DC
Time Scale: 8µs/div
Ch1 (Blue): VOUT 50mV/div AC
Ch2 (Cyan): PWM 5V/div DC
Ch3: (Violet): Load Trigger 5V/div DC
Time Scale: 8µs/div
Figure 5.31 Open Loop Bode Plots
40
30
0
Max Caps - Gain
-30
Min Caps - Gain
Max Caps - Phase
Min Caps - Phase
20
-60
10
0
-90
-10
-20
-30
-40
-120
-150
-180
1
10
Frequency [kHz]
100
