Operate in API mode
Frame descriptions
64-bit I/O Sample Indicator - 0x82
Description
This frame type is emitted when a device configured with legacy API output— = 2— receives an I/O
sample frame from a remote device configured to use 64-bit source addressing—MY = 0xFFFE. Only
devices running in API mode will send I/O samples out the serial port.
Note This frame format is deprecated and should only be used by customers who require
compatibility with legacy Digi RF products. For new designs, we encourage you to use I/O Sample
Indicator - 0x92 for reception of I/O samples.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
specifications.
Frame
Field
Offset
Size
Description
0
8-bit
Start
Delimiter
Indicates the start of an API frame.
1
3
4
16-bit
8-bit
Length
Number of bytes between the length and checksum.
64-bit I/O Sample Indicator - 0x82
Frame type
The sender's 64-bit IEEE address.
64-bit
64-bit
source
address
12
13
8-bit
8-bit
RSSI
Received Signal Strength Indicator. The Hexadecimal equivalent
of (-dBm) value. For example if RX signal strength is -40 dBm,
then 0x28 (40 decimal) is returned.
Options
Bit field of options that apply to the received message:
n
Bit 0: Reserved
n
Bit 1: Packet was sent as a broadcast [0x02]
n
Bit 2: 802.15.4 only - Packet was broadcast across all
PANs [0x04]
Note Option values may be combined.
14
8-bit
Number of The number of sample sets included in the payload.
samples
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
129
