Operate in API mode
Frame descriptions
Examples
Each example is written without escapes (AP = 1) and all bytes are represented in hex format. For
brevity, the start delimiter, length, and checksum fields have been excluded.
64-bit unicast
A device with the 64-bit address of 0013A20087654321 sent a unicast transmission to a specific
device with the payload of "TxData". The following frame is emitted if the destination is configured
with AO = 2.
7E 00 11 80 00 13 A2 00 12 34 56 78 5E 01 54 78 44 61 74 61 11
Frame type
64-bit source
RSSI
Rx options
Received data
0x0013A200
87654321
0x80
0x5E
0x01
0x547844617461
Output
-94 dBm
ACK was sent
"TxData"
