TLV9001, TLV9002, TLV9004
www.ti.com
SBOS833A –OCTOBER 2017–REVISED DECEMBER 2017
TLV9004 D, PW Packages
14-Pin SOIC, TSSOP
Top View
OUT A
-IN A
+IN A
V+
1
2
3
4
5
6
7
14 OUT D
13 -IN D
A
D
12 +IN D
11 V-
+IN B
-IN B
OUT B
10 +IN C
9
8
-IN C
B
C
OUT C
Pin Functions: TLV9004
PIN
I/O
DESCRIPTION
NAME
–IN A
+IN A
–IN B
+IN B
–IN C
+IN C
–IN D
+IN D
OUT A
OUT B
OUT C
OUT D
V–
NO.
2
I
I
Inverting input, channel A
3
Noninverting input, channel A
Inverting input, channel B
Noninverting input, channel B
Inverting input, channel C
Noninverting input, channel C
Inverting input, channel D
Noninverting input, channel D
Output, channel A
6
I
5
I
9
I
10
13
12
1
I
I
I
O
O
O
O
—
—
7
Output, channel B
8
Output, channel C
14
11
4
Output, channel D
Negative (lowest) supply or ground (for single-supply operation)
Positive (highest) supply
V+
