TABLE 1. PIN DESCRIPTION
FIGURE 4. LOGIC DIAGRAM
Pin Name
A21–A0
DQ0-DQ14
DQ15 / A-1
CE#
Function
EN29GL064
A21–A0
DQ0 – DQ15
(A-1)
A0 – A21
Data input/output.
DQ15 (data input/output, word mode),
A-1 (LSB address input, byte mode)
Reset#
Chip Enable
CE#
OE#
OE#
Output Enable
RY/BY#
WE#
RESET#
RY/BY#
WE#
Hardware Reset Pin
Ready/Busy Output
Write Enable
Byte#
Vcc
Supply Voltage (2.7-3.6V)
Ground
Vss
VIO
V I/O Input.
BYTE#
WP#/ACC
RFU
Byte/Word mode selection
Write Protect / Acceleration Pin
Reserved for future use.
Not Connected to anything
