EM78P809N
8-Bit Microcontroller
4.9.1 Timer Mode:
In Timer mode, counting up is performed using the internal clock. When the contents of
the up-counter matched with the TCR2 (TCR2H+TCR2L), then interrupt is generated
and the counter is cleared. Counting up resumes after the counter is cleared.
Internalclock
0
1
2
3
4
n-3
n-2
n-1
n
0
2
3
5
Up-counter
TCR2
1
n
counter
clear
match
TC2interrupt
Fig. 20. Timer Mode Timing Chart
4.9.2 Counter Mode:
In Counter mode, counting up is performed using the external clock input pin (TC2 pin)
and either rising or falling can be selected by setting TC2ES. When the contents of
the up-counter matched with the TCR2 (TCR2H+TCR2L), then interrupt is generated
and the counter is cleared. Counting up resumes after the counter is cleared.
TC2Pin
0
1
2
3
n-2
n-1
n
0
2
3
4
Up-counter
TCR2
1
n
counter
clear
match
TC2interrupt
Fig. 21. Counter Mode Timing Chart (TC2ES = 1)
4.9.3 Window Mode
In Window mode, counting up is performed on the rising or falling edge of the pulse
that is logical AND of an internal clock and the TC2 pin (window pulse). When the
contents of the up-counter matched with the TCR2 (TCR2H+TCR2L), then interrupt is
generated and the counter is cleared. The frequency (window pulse) must be slower
than the selected internal clock.
Writing to the TCR2L, the comparison is inhibited until TCR2H is written.
Product Specification (V1.0) 07.26.2005
• 41
(This specification is subject to change without further notice)
